25G光模塊
永鼎光電子出品高性能、低成本的SFP28、SFP28 BIDI、SFP28 CWDM、SFP28 AOC、SFP28 DWDM光模塊，以更快，只為更好的企業理念為客戶提供響應更快和更優質的服務。
產品特性

產品支持SFP MSA、 SFF-8431、SFF-8472協議

產品速率范圍從10G到28.05G

商業級/工業級應用

應用

25G以太網

OTN

CPRI/eCPRI

規格參數
Type Part Number Package Data Rate Wavelength Reach Transmitter Receiver TX output (dBm) RX Sensitivity (dBm) Power Consumption (W) Interface Temperature Application
SFP28 Transeiver FLS25C010S SFP28 25G 850nm 100M VCSEL PIN 2~-4 -8.5 <1 LC 0℃~70℃ 25GBASE-SR
FLS25C030S SFP28 25G 850nm 300M VCSEL PIN 2~-4 -8.5 <1 LC 0℃~70℃ 25GBASE-SR
FLS25C110S SFP28 25G 1310nm 10KM DFB PIN 2~-4 -14 <1 LC 0℃~70℃ 25GBASE-LR
FLS25I110S SFP28 25G 1310nm 10KM DFB PIN 2~-4 -14 <1 LC -40℃~85℃ 25GBASE-LR
FLS32C110S SFP28 28.05G 1310nm 10KM DFB PIN 2~-4 -13 <1 LC 0℃~70℃ 32GFC
FLS32I111S SFP28 28.05G 1310nm 10KM DFB PIN 2~-4 -13 <1 LC -40℃~85℃ 32GFC
SFP28 AOC FLS25C011S-Lxx SFP28 25G 850nm 0.5M~30M VCSEL PIN - - - AOC 0℃~70℃ 25GBASE-SR
SFP28 BIDI Transeiver FLS25C411S-C27 SFP28 25G TX:1270nm/RX:1330nm 10KM DFB PIN 2~-4 -13 <1.2 LC 0℃~70℃ 25GBASE-LR
FLS25C412S-C33 SFP28 25G TX:1330nm/RX:1270nm 10KM DFB PIN 2~-4 -13 <1.2 LC 0℃~70℃ 25GBASE-LR
FLS25I411S-C27 SFP28 25G TX:1270nm/RX:1330nm 10KM DFB PIN 2~-4 -13 <1.2 LC -40℃~85℃ 25GBASE-LR
FLS25I412S-C33 SFP28 25G TX:1330nm/RX:1270nm 10KM DFB PIN 2~-4 -13 <1.2 LC -40℃~85℃ 25GBASE-LR
FLS25I441S-C27 SFP28 25G TX:1270nm/RX:1330nm 40KM DFB APD 6~0 -18 <2 LC -40℃~85℃ 25GBASE-ER
FLS25I442S-C31 SFP28 25G TX:1330nm/RX:1270nm 40KM DFB APD 6~0 -18 <2 LC -40℃~85℃ 25GBASE-ER
FLS25I411S-C27 SFP28 25G TX:1270nm/RX:1310nm 10KM DFB PIN 2~-4 -13 <1.2 LC -40℃~85℃ 25GBASE-LR
FLS25I412S-C31 SFP28 25G TX:1310nm/RX:1270nm 10KM DFB PIN 2~-4 -13 <1.2 LC -40℃~85℃ 25GBASE-LR
FLS25I441S-C27 SFP28 25G TX:1270nm/RX:1310nm 40KM DFB APD 6~0 -18 <2 LC -40℃~85℃ 25GBASE-ER
FLS25I442S-C31 SFP28 25G TX:1310nm/RX:1270nm 40KM DFB APD 6~0 -18 <2 LC -40℃~85℃ 25GBASE-ER
FLS25I443S-C29 SFP28 25G TX:1290nm/RX:1310nm 40KM DFB APD 6~0 -18 <2 LC -40℃~85℃ 25GBASE-ER
FLS25I444S-C31 SFP28 25G TX:1310nm/RX:1290nm 40KM DFB APD 6~0 -18 <2 LC -40℃~85℃ 25GBASE-ER
Type Part Number Package Data Rate Wavelength Reach Transmitter Receiver TX output (dBm) RX Sensitivity (dBm) Power Consumption (W) Interface Temperature Application
SFP28 DWDM Transeiver FLS25C113S-D17~H61 SFP28 25G DWDM 2KM DFB PIN 5~-3 -11.3 <2 LC 0℃~70℃ 25GBASE-LR
FLS25I113S-D17~H61 SFP28 25G DWDM 2KM DFB PIN 4~-1 -19 <2.3 LC -40℃~85℃ 25GBASE-LR
FLS25C115S-D17~H61 SFP28 25G DWDM 2KM DFB APD 4~-1 -19 <2 LC 0℃~70℃ 25GBASE-LR
FLS25I115S-D17~H61 SFP28 25G DWDM 2KM DFB APD 4~-1 -19 <2.3 LC -40℃~85℃ 25GBASE-LR
SFP28 CWDM Transeiver FLS25C112S-C27~C37 SFP28 25G CWDM 10KM DFB PIN 6~1 -14 <1 LC 0℃~70℃ 25GBASE-LR
FLS25I112S-C27~C37 SFP28 25G CWDM 10KM DFB PIN 6~1 -14 <1 LC -40℃~85℃ 25GBASE-LR
FLS25C114S-C39~C61 SFP28 25G CWDM 10KM EML PIN 6~0 -14 <2 LC 0℃~70℃ 25GBASE-LR
FLS25I114S-C39~C61 SFP28 25G CWDM 10KM EML PIN 6~0 -14 <2 LC -40℃~85℃ 25GBASE-LR
FLS25C118S-C27~C37 SFP28 25G CWDM 10KM DFB APD 3~0 -13 <2 LC 0℃~70℃ 25GBASE-LR
FLS25I118S-C27~C37 SFP28 25G CWDM 10KM DFB APD 3~0 -13 <2.3 LC -40℃~85℃ 25GBASE-LR
FLS25C117S-C39~C61 SFP28 25G CWDM 10KM EML APD 3~0 -13 <2 LC 0℃~70℃ 25GBASE-LR
FLS25I117S-C39~C61 SFP28 25G CWDM 10KM EML APD 3~0 -13 <2.3 LC -40℃~85℃ 25GBASE-LR
